Wooden Gazebo Hexagon 400(L) x 400(W) x 330(H) · SS-012796
Price on request
SKU: SS-012796
Product Technical Specifications Seating Area: 400 × 400 cm (157 x 157 in) Roof Area: 470 × 470 cm (185 x 185 in) Height: 330 cm (130 in) Wood Characteristics: The structure is built from first‑grade Yellow Pine (Pinus sylvestris). Lumber sections are cut to a maximum tolerance of ±2 mm (0.1 in), overall dimensions to ±20 mm (0.8 in). Required wood qualities: - Knots: Up to four solid knots per meter are allowed, provided total knot width does not exceed one‑quarter of the board width. No rotten, decayed, partially fused, or missing knots. - Cracks: No ring cracks; fine hairline cracks (1‑2 mm (0.1 in)) are permitted within tolerance. - Resin pockets: No more than one resin pocket per meter, not longer than 10 cm (3.9 in). No leaking resin, inner bark, rot cavities, or insect holes. - Bending: Deflection ≤ 1/50 of member length. - Impact: Marks ≤ 1/100 of member width. - Twisting: ≤ 2 mm (0.1 in) per meter. - Flexure to grain: Deflection between 1/50 and 1/100 of member length. - Sanding: All visible surfaces sanded smooth, free of splinters. The wood will be finished with a white lacquer. Primary Supports: Six pine legs, each at least 90 × 90 mm (3.5 x 3.5 in), cut with diamond‑tip knives and featuring decorative motifs. Leg height 240 cm (94.5 in). Roof: Roof framing uses 50 × 100 mm (2 x 3.9 in) timber. Two corners of each rafter are shaped on a router. Rafters are fastened with wooden cleats, lacquered cladding, or fiber material. Oily‑treated membranes are attached with wide‑head nails, followed by American‑style shingles installed with the same nails. The eave board is reinforced with at least 30 × 130 mm (1.2 x 5.1 in) timber, also cut with diamond‑tip knives and secured to the rafters with galvanized wood screws. The roof connection uses eight pieces of at least 50 × 50 mm (2 x 2 in) timber, each corner cut at specific angles, forming a joint that connects to the primary support on one side and the eave board on the other. All fixed connections use stainless‑steel wood screws; connections between primary supports and roof use specially galvanized wood screws. Pigeon: height 450 mm (17.7 in). roof rafters are 50 × 50 mm (2 x 2 in) timber. Between the upper and lower 50 × 50 mm (2 x 2 in) members, 30‑mm‑spaced 30 × 15 mm (1.2 x 0.6 in) wooden slats are installed, fastened with shiplap wood, and oily‑treated membranes are secured with wide‑head nails. The roof is covered with a clover‑leaf‑shaped American shingle installed with the same nails. The eave uses 90 × 20 mm (3.5 x 0.8 in) timber shaped with a diamond‑tip decorative knife. Lower Guardrail: Height 75 cm (29.5 in). Frames are 50 × 50 mm (2 x 2 in) timber, sanded on all sides and edged with diamond‑tip knives, mounted to primary supports with galvanized wood screws. Intermediate decorative pieces, 40 × 50 mm (1.6 x 2 in), are also cut with diamond‑tip knives and attached with galvanized screws and clear specialty wood glue. Upper Guardrail: Width 35 cm (13.8 in). Frames are identical to the lower guardrail (50 × 50 mm (2 x 2 in) sanded timber edged with specialty knives) and attached with galvanized wood screws. Same 40 × 50 mm (1.6 x 2 in) decorative pieces are used. Seating Unit: Six wooden L‑legs, each at least 4 × 9 cm (1.6 x 3.5 in). Each leg connects one end to a primary support and the other end to a seating slat. Four decorative wooden slats per side, shaped with diamond‑tip knives, are fastened with galvanized screws. Anchors: At the base of each support leg, an 18 × 13 × 3 mm (0.7 x 0.5 x 0.1 in) flange is welded to a 15 × 8 × 2 mm (0.6 x 0.3 x 0.1 in) plate; a 13 × 8 × 3 mm (0.5 x 0.3 x 0.1 in) plate has two anchor holes, and each 15 × 8 × 2 mm (0.6 x 0.3 x 0.1 in) plate has three 6 mm (0.2 in) screw holes. Anchors are bolted to footings with steel dowels, protecting the timber from water contact and securing the legs to the ground. Gazebo anchors are welded on at least two sides of a fabricated flange minimum 2.5 mm (0.1 in) thick. Six specialty screws are installed per leg for the structural connection and two dowel screws per leg for the ground connection. All metal components are powder‑coated with a polyester‑based finish. Impregnation: [Technical impregnation details would follow here.]
