Wood – Bracketed Octagonal Picnic Gazebo 400(L)x400(W)x330(H)
Price on request
SKU: SS-011400
Seat Area: 400 x 400 cm (157 x 157 in) Roof Size: 470 x 470 cm (185 x 185 in) Height: 330 cm (130 in) Wood: 1st‑grade spruce/pine Wood Color: White Roof Covering: Special roof covering material made of shingle over laminate or fiberglass. Shingle Color: Green Seating Unit: Included Table: None Wood Features: The wood material used for manufacturing will be 1st‑grade Spruce (Pinus sylvestris) lumber. Wood sections will be fabricated with a maximum tolerance of ±2 mm (0.1 in), and wood dimensions with a maximum tolerance of ±20 mm (0.8 in). Required wood characteristics include: Knots – each meter may contain up to four solid knots. The total knot diameter will not exceed one‑quarter of the piece width. No rotten, defective, partially fused, or fallen knots will be present. Cracks – No ring cracks. Microscopic cracks (1‑2 mm (0.1 in)) may be present. Pressure‑treated material may have permissible axial and radial cracks within tolerance limits. Resin pockets – Each meter may contain at most one resin pocket not exceeding 10 cm (3.9 in) in length. No leaking or pulling resin, inner shell, rot cavities, insect holes, or manufacturing defects will be present; only allowed deviations within specified tolerances. Deflection – Will not exceed 1/50 of the member length. Impact – Will not exceed 1/100 of the member width. Twist – Will not exceed 2 mm (0.1 in) per meter length. Blade – Tolerated between 1/50 and 1/100 of the member length. Sanding – All visible surfaces will be sanded smooth. Anchorage: Two 15 × 8 × 2 mm (0.6 x 0.3 x 0.1 in) welding plates will be welded onto the underside of the carrier legs over an 18 × 13 × 3 mm (0.7 x 0.5 x 0.1 in) flange; two 13 × 8 × 3 mm (0.5 x 0.3 x 0.1 in) plates will be drilled for anchor bolts; each 15 × 8 × 2 mm (0.6 x 0.3 x 0.1 in) plate will have three 6 mm (0.2 in) screw holes. Anchors will be bolted to the carriers and also attached to the floor via steel dowels, preventing wood contact with water and securing the carrier legs. Gazebo anchors will be fabricated by welding flanges at least 2.5 mm (0.1 in) thick around a minimum of two sides. Six special screws will be installed on each leg for the vertical connection, and two doweled screws per leg for floor attachment. All metal components will be powder‑coated with polyester‑based paint in a furnace.
